MIL-DTL-81963C
R1
R2
R1
DC
DC SOURCE
AMPLIFIER
RECORDER
M
R4
R3
R2
CENTER
MOTOR
SCALE
SERVOCOMPONENT
DC METER
UNDER TEST
M
-
MOTOR, 1 REV/MIN.
R1
-
RESISTOR, DECADE, 1K
R2, R3
-
RESISTOR, DECADE, 10K
R4
-
RESISTOR, DECADE, 10 OHM
NOTE: A current limiting resistor (1K), if required, would be connected in series with the "dc"
source.
FIGURE 13. Brush contact resistance variation test circuit.
40
